Information

This product is no longer available. You can still find all information and data on this page. If you have any further questions, our support team will be happy to help you.

Flashlight i4

i-Series

Technologien

Advanced Focus System

Nr: 500753

7 years

Get seven years warranty upon registration.

See our terms and conditions.

Ledlenser i4

A battery-powered pen light with excellent light output, a run time of up to 20 hours1 and always easy to store: That's the Ledlenser i4! Equipped with the patented Advanced Focus System for seamless and precise focusing of the light beam, it is the perfect companion for long, focused work you will never want to be without.

Battery-powered – by two standard AAA Alkaline batteries
Superior light output despite a compact size – up to 80 meter beam distance¹ and up to 120 lumen¹ Luminous flux
From a homogeneous, circular low beam (defocused) to a sharply bundled high beam (focused) – the patented³ Advanced Focus System with reflector lens creates efficient, customized light
Protected against dust and water – IP54
For a long lamp life – durable metal housing

Scope of delivery

1 set of batteries - AAA

Technical data

LED

Beam distance (in m) ¹ 80

Max. Luminous flux (in lm) ¹ 120

Lightsource quantity 1

CRI 65

Lightsource color temperature 6000 - 8000

1 Measured values according to ANSI/PLATO FL 1 at the respective setting. If no setting is explicitly named, the values for luminous flux (lumen/lm) and luminous range (metres/m) refer to the brightest setting and the values for luminous duration (hours/h) to the lowest setting. A boost function (if available) can be used several times, but is only available for a short time at a time. In case the lamp is equipped with coloured LEDs, the measured values are given with white light or the white LED. If the lamp has different energy modes, the "energy saving mode" is the basis for the measurement.
Power supply

Runtime (in hours) ¹ 20

Rechargeable No

Battery ² Micro (AAA) 1.5V

1 Measured values according to ANSI/PLATO FL 1 at the respective setting. If no setting is explicitly named, the values for luminous flux (lumen/lm) and luminous range (metres/m) refer to the brightest setting and the values for luminous duration (hours/h) to the lowest setting. A boost function (if available) can be used several times, but is only available for a short time at a time. In case the lamp is equipped with coloured LEDs, the measured values are given with white light or the white LED. If the lamp has different energy modes, the "energy saving mode" is the basis for the measurement.

2 Calculated value of the capacity in watt hours (Wh). This applies to the battery(ies) contained in the delivery condition of the respective item or, in the case of lamps with rechargeable battery, to the rechargeable battery(ies) contained herein in a fully charged condition.
Case

Dimensions

Length (in mm) 140

Head diameter (in mm) 15

Tube diameter (in mm) 15

Weight (in g) 55

Material

Materials Aluminum alloy

Water and dust resistance IP54

Drop test height (in m) 2

Working temperature (in C°) -20 - 40
Downloads

Name Size Typ

P4X_i4_QUG_V.03_171020 418,99 kB pdf

DECLARATION OF CONFORMITY i4_2018-01-02 639,47 kB pdf
